ATB73

ATB72

ATB71

Resolution

320x240

220x160

160x120

Total pixels

300,000

300,000

192,00

T em peratu re ra nge

-20°C to 300°C (-4°F to 572°F)

-20°C to 450°C (-4°F to 842°F)

-20°C to 450°C (-4°F to 842°F)

Display

2,8" full angle TFT display screen

*

*

*

FOV/Shortest focal length

35°x26° / 0.15m

*

*

*

Thermal sensitivity

0.07°C

*

*

*

Image frequency

9Hz

*

*

*

Measuring accuracy

±2°C ±2%
(if over 300°C, accuracy is ±5%)

*

*

*

Wavelength range

3-14um

*

*

*

Emissivity

Adjustable from 0.01 to 1.0

*

*

*

Focus Mode

Fixed

*

*

*

Palette

Rainbow, iron oxide red, cold color, black & white, white & black

*

*

*

Image Storage

Built-in 3G
(above 20 thousand image stored)

*

*

*

File Format

JPG

*

*

*

Automatiс pоwer-off time

5 minutes / 20 minutes / not power off automatically

*

*

*

Operating temperature

0°C to 45°C

*

*

*

Storage ternperature

-20°C to 60°C

*

*

*

Humidity

< 85% RH

*

*

*

USB

Micro USB 2.0

*

*

*

Working Time

2-3 hours

*

*

*

Power Supply

Built-in chargeable 18650 battery

*

*

*

Language

English, Chinese, Italian, German

*

*

*

Setting command

Unit, language, date, time, information

*

*

*

Pro duct site

69,4 x 225.0 x 93.4 mm

*

*

*

Weight

335g

*

*

*
